Bramley Chassis Hole Punches
- for Mild Steel & Stainless Steel
For cutting precision holes in sheet or panel, eliminating distortion to deliver a superior finish.
Model 010SET
- Set of 6 popular sizes (16, 20, 22, 25.4, 32 & 35 mm)
1/2” - 2” individual sizes available
- New 3 point design on punch for easier cutting
- Upgraded tool steel specification for increased life & performance
- For simple cutting of neat holes in sheetmetal
Individual protective packaging
Simple to use:
- Drill a hole 1/32” (0.8 mm) larger than drive screw
- Insert screw through die
- Place screw through hole in metal & screw on punch
- Turn drive screw with spanner or wrench until metal is cut
Individual Sizes
| MODEL | Size | Capacity (Mild Steel) | Capacity (Stainless Steel) | Bolt Thread |
|---|---|---|---|---|
| 010-12.5 | 1/2" (12.5mm) | 2mm | 1.6mm | M8 x 1.0 |
| 010-16 | 5/8" (16mm) | 2mm | 1.6mm | M8 x 1.0 |
| 010-19 | 3/4" (19mm) | 2mm | 1.6mm | M10 x 1.25 |
| 010-20 | 20mm | 2mm | 1.6mm | M10 x 1.25 |
| 010-22 | 7/8" (22mm) | 2mm | 1.6mm | M10 x 1.25 |
| 010-25.5 | 1" (25.5mm) | 2mm | 1.6mm | M12 x 1.25 |
| 010-28.5 | 1-1/8" (28.5mm) | 2.5mm | 2mm | M12 x 1.25 |
| 010-30 | 1-3/16" (30mm) | 2.5mm | 2mm | M12 x 1.25 |
| 010-32 | 1-1/4" (32mm) | 2.5mm | 2mm | M12 x 1.25 |
| 010-35 | 1-3/8" (35mm) | 2.5mm | 2mm | M12 x 1.25 |
| 010-38 | 1-1/2" (38mm) | 2.5mm | 2mm | M12 x 1.25 |
| 010-41.5 | 1-5/8" (41.5mm) | 2.5mm | 2mm | M20 x 1.5 |
| 010-44.5 | 1-3/4" (44.5mm) | 2.5mm | 2mm | M20 x 1.5 |
| 010-48 | 1-7/8" (48mm) | 2.5mm | 2mm | M20 x 1.5 |
| 010-51 | 2" (51mm) | 2.5mm | 2mm | M20 x 1.5 |
Set of 6 Chassis Punches
– Model 010SET
Counter Display Stand for 010-SET
